STM32F746G-DISCO IO assignment UM1907

40/49 DocID027942 Rev 3

C3 PI4 SAI2_MCLK_A -

C4 PK7 LTDC_DE -

C5 PK6 LTDC_B7 -

C6 PK5 LTDC_B6 -

C7 PG12 LTDC_B4 -

C8 PG10 SAI2_SD_B -

C9 PJ14 LTDC_B2 -

C10 PD5 OTG_FS_PowerSwitchOn -

C11 PD3 DCMI_D5 -

C12 PD1 FMC_D3_DA3 -

C13 PI3 ARDUINO D7 -

C14 PI2 ARDUINO D8 -

C15 PA11 USB_OTG_FS_DM -

D1 PC13 uSD_Detect -

D2 PF0 FMC_A0 -

D3 PI5 SAI2_SCK_A -

D4 PI7 SAI2_FS_A -

D5 PI10 LTDC_HSYNC -

D6 PI6 SAI2_SD_A -

D7 PK4 LTDC_B5 -

D8 PK3 LCD_BL_CTRL -

D9 PG9 DCMI_VSYNC -

D10 PJ15 LTDC_B3 -

D11 PD4 OTG_FS_OverCurrent -

D12 PD2 SDMMC_CMD -

D13 PH15 TP3 -

D14 PI1 ARDUINO SCK/D13 -

D15 PA10 USB_OTG_FS_ID -

E1 PC14/OSC32_IN RCC_OSC32_IN -

E2 PF1 FMC_A1 -

E3 PI12 LCD_DISP -

E4 PI9 LTDC_VSYNC -

E5 PDR_ON - Connected to PU R38

E6 BOOT0 - Connected to PD R45

E7 VDD - -

Table 10. STM32F746G-DISCO IO assignment (continued)

Pin No. Pin Name Signal or Label Comment
