AHB1
0x4002 3400 - 0x47FF FFFF 127 MB Reserved -
0x4002 3000 - 0x4002 33FF 1 KB CRC Section 16.4.6: CRC register map
0x4002 2400 - 0x4002 2FFF 3KB Reserved -
0x4002 2000 - 0x4002 23FF 1 KB Flash interface Section 5.7.14: FLASH register map
0x4002 1400 - 0x4002 1FFF 3 KB FMAC Section 18.4.9: FMAC register map
0X4002 1000 - 0x4002 13FF 1 KB RCC Section 7.4.31: RCC register map
0x4002 0C00 - 0x4002 0FFF 1 KB CORDIC Section 17.4.4: CORDIC register map
0x4002 0800 - 0x4002 0BFF 1 KB DMAMUX Section 13.6.7: DMAMUX register map
0x4002 0400 - 0x4002 07FF 1 KB DMA 2 Section 12.6.7: DMA register map
0x4002 0000 - 0x4002 03FF 1 KB DMA 1 Section 12.6.7: DMA register map
APB2
0x4001 7800 - 0x4001 FFFF 2KB Reserved -
0x4001 6800 - 0x4001 77FF 3 KB HRTIM Section 27.5.82: HRTIM register map
0x4001 5800 - 0x4001 67FF 4KB Reserved -
0x4001 5400 - 0x4001 57FF 1 KB SAI1 Section 40.5.19: SAI register map
0x4001 5000 - 0x4001 53FF 1 KB TIM20 Section 28.6.31: TIMx register map
0x4001 4C00 - 0x4001 4FFF 1KB Reserved -
0x4001 4800 - 0x4001 4BFF 1 KB TIM17 Section 30.8.22: TIM16/TIM17 register map
0x4001 4400 - 0x4001 47FF 1 KB TIM16 Section 30.8.22: TIM16/TIM17 register map
0x4001 4000 - 0x4001 43FF 1 KB TIM15 Section 30.7.23: TIM15 register map
0x4001 3C00 - 0x4001 3FFF 1 KB SPI4 Section 39.9.10: SPI/I2S register map
0x4001 3800 - 0x4001 3BFF 1 KB USART1 Section 37.7.15: USART register map
0x4001 3400 - 0x4001 37FF 1 KB TIM8 Section 28.6.31: TIMx register map
0x4001 3000 - 0x4001 33FF 1 KB SPI1 Section 39.9.10: SPI/I2S register map
0x4001 2C00 - 0x4001 2FFF 1 KB TIM1 Section 28.6.31: TIMx register map
0x4001 0800 - 0x4001 2BFF 9KB Reserved -
0x4001 0400 - 0x4001 07FF 1 KB EXTI Section 15.5.13: EXTI register map
0x4001 0300 - 0x4001 03FF
1KB
OPAMP Section 25.5.13: OPAMP register map
0x4001 0200 - 0x4001 02FF COMP Section 24.6.2: COMP register map
0x4001 0030 - 0x4001 01FF VREFBUF Section 23.4.3: VREFBUF register map
0x4001 0000 - 0x4001 0029 SYSCFG Section 10.2.11: SYSCFG register map
Table 3. STM32G4 Series memory map and peripheral register boundary
addresses
(1)
(continued)
Bus Boundary address
Size
(bytes)
Peripheral Peripheral register map
