1 Features
• STM32H747XIH6 and STM32H757XIH6 microcontrollers with 2 Mbytes of Flash memory and 1 Mbyte of
RAM in TFBGA240+25 package
• 4” 480×800 TFT color LCD with MIPI DSI
SM
interface and capacitive touchpanel
• Ethernet compliant with IEEE-802.3-2002
• USB OTG_HS and OTG_FS
• I
2
C compatible serial interface
• RTC with rechargeable backup battery
• SAI audio DAC
• ST-MEMS digital microphones
• 8-Gbyte (or more) SDIO3.0 interface microSD™ card
• 8 M×32bit SDRAM, 1 M×16bit SRAM and 8 M×16bit NOR Flash memory
• 1-Gbit Twin Quad-SPI NOR Flash memory or two 512-Mbit Quad-SPI NOR Flash memories
• Potentiometer
• 4 color user LEDs
• Reset, wakeup, tamper or key buttons
• Joystick with 4-direction control and selector
• Board connectors
– Power jack
– 3 USB interfaces with Micro-AB connector
– RS-232 communications
– Ethernet RJ45
– FDCAN compliant connection
– Stereo headset jack including analog microphone input
– 2 audio jacks for external speakers
– microSD™ card
– JTAG/SWD and ETM trace
– Extension connectors and memory connectors for daughterboard or wire-wrap board
• Flexible power-supply options: ST-LINK USB V
BUS
or external sources
• On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the STM32Cube MCU Package
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR
™
, Keil
®
, GCC-
based IDEs
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2525
Features
UM2525 - Rev 3
page 2/69
