8 STM32H7x7I-EVAL I/O assignment

Table 36. STM32H7x7I-EVAL I/O assignment

Pin number Pin name Default function Alternate function

N5 PA0-WKUP KEY_WKUP0 -

N4 PA1 RMII_REF_CLK -

N3 PA2 RMII_MDIO -

U2 PA3 ULPI_D0 -

U3 PA4 EXT_RESET -

T3 PA5 ULPI_CK -

R3 PA6 GPIO_LCD_BACKLIGHT_CTRL -

R5 PA7 RMII_CRS_DV -

E15 PA8 MCO1 -

D15 PA9 USB_FS2_VBUS -

D14 PA10 USB_FS2_ID -

E17 PA11 USB_FS2_DM FDCAN_1_RXFD

E16 PA12 USB_FS2_DP FDCAN_1_TXFD

C15 PA13 JTMS-SWDIO -

B14 PA14 JTCK-SWCLK -

A14 PA15 JTDI CEC

U5 PB0 ULPI_D1 -

T5 PB1 ULPI_D2 -

R6 PB2 QSPI_CLK -

C6 PB3 JTDO/TRACESWO -

B7 PB4 NJTRST -

A5 PB5 ULPI_D7 -

B5 PB6 I2C_1_SCL -

C5 PB7 I2C_1_SDA -

D5 PB8 SDIO_1_CKIN -

D4 PB9 SDIO_1_CDIR -

P11 PB10 ULPI_D3 -

P12 PB11 ULPI_D4 -

T14 PB12 ULPI_D5 USB_FS1_ID

U14 PB13 ULPI_D6 USB_FS1_VBUS

U15 PB14 USART1_TX USB_FS1_DM

T15 PB15 USART1_RX USB_FS1_DP

L2 PC0 ULPI_STP -

M2 PC1 RMII_MDC PDM1_D1

M3 PC2 DFSDM_CKOUT -

M4 PC3 DFSDM_DATA1 -

T4 PC4 RMII_RXD0 -

UM2525

STM32H7x7I-EVAL I/O assignment

UM2525 - Rev 3

page 37/69
