Pin number Pin name Default function Alternate function

U4 PC5 RMII_RXD1 -

F14 PC6 SDIO_1_D0DIR -

F13 PC7 SDIO_1_D123DIR -

E13 PC8 SDIO_1_D0 -

E14 PC9 SDIO_1_D1 -

A13 PC10 SDIO_1_D2 -

B13 PC11 SDIO_1_D3 -

C12 PC12 SDIO_1_CK -

E3 PC13-ANTI_TAMP KEY_TAMP_1/WKUP2 -

C2 PC14-OSC32_IN OSC32_IN -

C1 PC15-OSC32_OUT OSC32_OUT -

D13 PD0 FMC_D2 -

E12 PD1 FMC_D3 -

D12 PD2 SDIO_1_CMD -

B12 PD3 GPIO_CAN_STANDBY -

A12 PD4 FMC_NOE -

A11 PD5 FMC_NWE -

B11 PD6 FMC_NWAIT -

C11 PD7 FMC_NE1 -

U16 PD8 FMC_D13 -

T17 PD9 FMC_D14 -

T16 PD10 FMC_D15 -

R15 PD11 FMC_A16 -

R16 PD12 FMC_A17 -

R17 PD13 FMC_A18 -

P16 PD14 FMC_D0 -

P15 PD15 FMC_D1 -

C4 PE0 FMC_NBL0 -

B4 PE1 FMC_NBL1 -

C3 PE2 PDM1_CK1 FMC_A23/TRACECLK/ SAI_1_MCLK_A

D3 PE3 SAI1_SD_B FMC_A19/TRACED0

D2 PE4 SAI1_FS_A FMC_A20/TRACED1

D1 PE5 SAI1_SCK_A FMC_A21/TRACED2

E5 PE6 SAI1_SD_A FMC_A22/TRACED3

U9 PE7 FMC_D4 -

T9 PE8 FMC_D5 -

P9 PE9 FMC_D6 -

N9 PE10 FMC_D7 -

P10 PE11 FMC_D8 -

R10 PE12 FMC_D9 -

UM2525

STM32H7x7I-EVAL I/O assignment

UM2525 - Rev 3

page 38/69
