Pin number
Pin name
Default function
Alternate function
T10
PE13
FMC_D10
-
U10
PE14
FMC_D1
1
-
R1
1
PE15
FMC_D12
-
G4
PF0
FMC_A0
-
G3
PF1
FMC_A1
-
G1
PF2
FMC_A2
-
H4
PF3
FMC_A3
-
J5
PF4
FMC_A4
-
J4
PF5
FMC_A5
-
K2
PF6
QSPI_BK1_IO3
-
K3
PF7
QSPI_BK1_IO2
-
K4
PF8
QSPI_BK1_IO0
-
L4
PF9
QSPI_BK1_IO1
-
L3
PF10
GPIO_DSI_RST
-
T7
PF1
1
SDR_SDNRAS
-
R7
PF12
FMC_A6
-
P7
PF13
FMC_A7
-
P8
PF14
FMC_A8
-
R9
PF15
FMC_A9
-
T8
PG0
FMC_A10
-
U8
PG1
FMC_A1
1
-
H16
PG2
FMC_A12
-
H15
PG3
FMC_A13
-
H14
PG4
FMC_A14 / SDR_BA0
-
G14
PG5
FMC_A15 / SDR_BA1
-
G15
PG6
QSPI_BK1_NCS
-
F16
PG7
SAI_1_MCLK_A
-
F15
PG8
SDR_SDCLK
-
A10
PG9
QSPI_BK2_IO2
-
A9
PG10
FMC_NE3
-
B9
PG1
1
RMII_TX_EN
-
C9
PG12
RMII_TXD1
-
D9
PG13
RMII_TXD0
-
D8
PG14
QSPI_BK2_IO3
-
D6
PG15
SDR_SDNCAS
-
J2
PH0 - OSC_IN
OSC_IN
-
J1
PH1 - OSC_OUT
OSC_OUT
-
N2
PH2
QSPI_BK2_IO0
-
P2
PH3
QSPI_BK2_IO1
-
P3
PH4
ULPI_NXT
-
UM2525
STM32H7x7I-EV
AL I/O assignment
UM2525
-
Rev 3
page 39/69
38
40
