Pin Description Alternate function How to disconnect with function block on STM32H7x7I-EVAL board
58 PJ10 - -
60 +5V - -
Table 24. Daughterboard extension connector CN7
Pin Description Alternate function
How to disconnect with function block on STM32H7x7I-EVAL
board
1 PF10 GPIO_DSI_RST Remove R286, Disconnect CN15
3 PC15 OSC32_OUT Remove R17, Close SB4
5 PI14 - -
7 PI13 - -
9 PC13 KEY_TAMP_1/WKUP2 Remove R193
11 PB8 SDIO_1_CKIN Remove R161
13 PK7 - -
15 PB3 JTDO/TRACESWO Remove R60
17 PK6 LED4 Remove R199
19 GND - -
21 PK4 LED2 Remove R201
23 PK3 LED1 Remove R202
25 PG13 RMII_TXD0 -
27 PA0 KEY_WKUP0 Remove R173, R203
29 PJ15 - -
31 PJ11 - -
33 PC12 SDIO_1_CK Add R139 10Kohm, Remove R83
35 PA15 JTDI/CEC Remove R61, Disconnect CN15
37 PG11 RMII_TX_EN -
39 GND - -
41 PD2 SDIO_1_CMD Add R139 10Kohm
43 PA13 JTMS-SWDIO Remove R55
45 PC6 SDIO_1_D0DIR Add R139 10Kohm, Remove SB58
47 PA10 USB_FS2_ID Disconnect CN18
49 D5V - -
51 PG7 SAI_1_MCLK_A/ETH_nINT Remove SB56, SB62
53 PC9 SDIO_1_D1 Add R139 10Kohm
55 PK0 - -
57 PK1 - -
59 GND - -
2 PC2 DFSDM_CKOUT Not to dial SW2 to the middle
4 PC14 OSC32_IN Remove R18, Close SB1
6 PI12 - -
8 PA2 RMII_MDIO Remove R47
UM2525
Daughterboard extension connector CN6 and CN7
UM2525 - Rev 3
page 26/69
