Pin Description Alternative function

How to disconnect with function block on

STM32H7x7I-EVAL board

25 PE0 NBL0 -

27 PG10 NE3 -

29 GND - -

31 PD0 D2 -

33 PI2 D26 -

35 PI1 D25 -

37 PI0 D24 -

39 PH13 D21 -

2 PH7 SDCKE1 -

4 PE5 A21/SAI1_SCK_A/TRACED2 Open SB41, SB42

6 PD6 NWAIT -

8 PF2 A2 -

10 GND - -

12 PF1 A1 -

14 PF0 A0 -

16 PE2 A23/PDM1_CK1/ SAI1_MCLK_A /TRACECLK Open SB11, SB15, SB57

18 PI7 D29 -

20 PI9 D30 -

22 PI6 D28 -

24 PD7 NE1 -

26 PD5 NWE -

28 PD4 NOE -

30 GND - -

32 PD1 D3 -

34 PI3 D27 -

36 PH15 D23 -

38 PH14 D22 -

40 +3.3V - -

UM2525

Memory connector CN11 and CN12

UM2525 - Rev 3

page 31/69

ST STM32H757I-EVAL User Manual
