9 STM32WB5MM-DK board information
9.1 Product marking
The stickers located on the top or bottom side of the PCB provide product information:
• Product order code and product identification for the first sticker
• Board reference with revision, and serial number for the second sticker
On the first sticker, the first line provides the product order code, and the second line the product identification.
On the second sticker, the first line has the following format: “MBxxxx-Variant-yzz”, where “MBxxxx” is the board
reference, “Variant” (optional) identifies the mounting variant when several exist, "y" is the PCB revision and "zz"
is the assembly revision, for example B01. The second line shows the board serial number used for traceability.
Evaluation tools marked as “ES” or “E” are not yet qualified and therefore not ready to be used as reference
design or in production. Any consequences deriving from such usage will not be at ST charge. In no event, ST will
be liable for any customer usage of these engineering sample tools as reference designs or in production.
“E” or “ES” marking examples of location:
• On the targeted STM32 that is soldered on the board (For an illustration of STM32 marking, refer to the
STM32 datasheet “Package information” paragraph at the www.st.com website).
• Next to the evaluation tool ordering part number that is stuck or silk-screen printed on the board.
Some boards feature a specific STM32 device version, which allows the operation of any bundled commercial
stack/library available. This STM32 device shows a "U" marking option at the end of the standard part number
and is not available for sales.
In order to use the same commercial stack in his application, a developer may need to purchase a part number
specific to this stack/library. The price of those part numbers includes the stack/library royalties.
9.2 STM32WB5MM-DK product history
9.2.1 Product identification DK32WB5MM$GU1
This product identification is based on the MB1292-WB5MM-B01 board.
It embeds the STM32W5MMG module with revision code "1". The limitations of this revision are detailed in the
errata sheet STM32WB5MMG module product errata (ES0525).
Product limitations
No limitation identified for this product identification.
9.3
Board revision history
9.3.1 Board MB1292 revision B-01
The revision B-01 is the initial release of the MB1292 board.
Board limitations
No limitation identified for this board revision.
UM2825
STM32WB5MM-DK board information
UM2825 - Rev 1
page 30/42
