Pin number Pin name Assignment on STM32WB5MM-DK
48 PB2
GPIO (ARDUINO
®
D7)
49 PC4
ADC1_IN13 (ARDUINO
®
A4)
50 PA8 SAI1_CK2 (Digital microphone)
51 PA9 SAI1_DI2 (Digital microphone)
52 PA7
SPI1_MOSI (SPI OLED display/ ARDUINO
®
D1/ RGB LED driver) *
53 PA6 LPUART_CTS (STMod+ pin 1)
54 PA5
ADC1_IN10 (STMod+ pin 19 and ARDUINO
®
D10)
55 PA4
SPI1_NSS (ARDUINO
®
D10)
56 PA3 QUADSPI_SCLK (Quad-SPI Flash memory)
61 PH0 SPI1_NSS (SPI chip select of OLED display)
62 PH1 GPIO_SELECT2 (RGB LED/Infrared LED)
63 PD14
TIM_CH1 (ARDUINO
®
D3)
64 PE1 DRDY (STTS22H temperature sensor)
65 PD13
GPIO (ARDUINO
®
D8)
66 PD12
GPIO (ARDUINO
®
D2)
67 PD7 QUADSPI_BK1_IO3 (Quad-SPI Flash memory)
68 PD2 INT signal for accelerometer/gyroscope sensor
69 PC9 D/C_DISP (Data or Ctrl OLED display)
70 PD3 QUADSPI_BK1_NCS (Quad-SPI Flash memory)
71 PC7 TSC_G4_IO2 (Touch key)
72 PE3 INT STMod+ (STMod+ pin 11)
73 PD4 SPI2_MOSI (STMod+ pin2)
74 PD9 INT signal for Time‑of‑Flight sensor
75 PD8 STMod+ RESET (STMod+ pin 12)
76 PD15
TIM1_CH2 (ARDUINO
®
D9)
77 PD10 TSC_G6_IO1 (Touch key)
78 PE2 GPIO_SELECT1 (Ctrl switch LPUART)
79 PE0
TIM16_CH1 (ARDUINO
®
D6)
80 PD5 QUADSPI_BK1_IO1 (Quad-SPI Flash memory)
81 PD6 QUADSPI_BK1_IO2 (Quad-SPI Flash memory)
82 PD11 TSC_G6_IO2 (Touch key)
83 PC8 RST_DISP (Reset OLED display)
UM2825
STM32WB5MM-DK I/O assignment
UM2825 - Rev 1
page 32/42
