Debug module (DM) UM0470

34/39 DocID14024 Rev 4

4.12.11 DM enable function register (DM_ENFCTR)

Address: 7F9Ah

Reset Value: 1111 1111 (FFh)

See Appendix A for a full description of the DM_ENFCTR register.

7 0

ENFCT7 ENFCT6 ENFCT5 ENFCT4 ENFCT3 ENFCT2 ENFCT1 ENFCT0

rw rw rw rw rw rw rw rw

Bits 7:0

ENFCTx Enable function

This bit is set and cleared by software. it allows to freeze a particular function of a

peripheral when the core is stalled. The ENFCTx bit definitions are product

dependent.

0: Function is frozen when the CPU is stalled by a DM

1: Function is active
