Stager YDE12000E - Preparation for Starting; Exhaust Pipe Installation

4. PREPARATION FOR STARTING
4.1 Installation of exhaust pipe
In case the genset must be run indoors, the engine exhaust gas must be drained to outdoor with
proper exhaust pipe.
(1) Do remove the cover on the exhuast side with spanner.
(2) Insert the exhuast pipe to the exhuast port.
(3) Enwind the silver paper or other thermal insulation material in the connection.
(4) Tighten the pipes with clamps.
(5) Tighten the cover to the genset.
WARNING
• Though the exhaust pipe is protected with thermal insulation material, do not touch it while the genset is running
to avoid scalding.
Ver. 3/Rev. 2; Data: 8.08.2022 38
