NOTICE
In case exhaust pipe is soft type, it must be arranged in a straight line as far as possible. The sharp turn arrangement is
forbidden, otherwise, it will cause large exhaust back pressure and impact genset running. Drill the hole in the wall per
exhaust pipe diameter and then tighten the pipe with bolts. It’s better to install a shell upon the exhaust pipe to prevent
the sand or snow from entering the pipe. It’s also suggested to install a water proof cover at the end of exhaust pipe
outdoor. The water proof is closed while the genset is not running and it will open when the genset is running.
WARNING
• Do check and clean the exhaust pipe before starting. If the sand or other things blocked the exhaust, the
exhaust cannot be drained out, accordingly the genset won’t run smoothly.
4.2 Fuel selection and use
• Fuel selection: OnIy use the Iight diesel, which is most
suitable for the engine.
GB/T252-1994 light diesel, 0# in summer, -10#, -20#,-35# in
winter.
• Keep dust and water out of the fuel: When filling the
fuel tank from drums, make sure that no dust or water
is mixed in the fuel. Otherwise the serious fuel
injection pump and nozzle problems will result.
• Do not overfill: Overfilling is very dangerous. Do not fill
the tank beyond the upper line of the red plug inside
the fuel filter.
WARNING
• Refuel in a well-ventilated area with the engine completely stopped and cooled.
• Do not smoke or allow flames or sparks in the area where the engine is refueled or where the fuel oil stored.
• Do not overfill the tank, make sure the filler cap is securely closed after refueling.
• Be careful not to spill fuel when refueling. If any fuel is spilled, wipe off the spilled fuel with a clean, dry and soft
fabric and make sure the area is dry before starting the engine.
4.3 Check and refiling the engine oil
WARNING
• Always check the engine oil level with the generating set on a level surface before starting and refill if
necessary.
• The engine may be damaged if operated with insufficient engine oil, it is also dangerous to refill too much
engine oil as sudden increase in engine speed may be caused by its combustion.
• Choose the proper engine oil per the ambient temperature.
• Select the most applicable engine oil. Do apply SAE10W-30, SAE15W-40 grade oil which is suitable for
common condition.
• lt is very important to select the applicable engine oil for keep up the performance and life of the generating set.
lf inferior engine oil is used, or if your engine oil is not replaced periodically, the risk of piston seizure, piston ring
sticking and accelerated wear of the cylinder liner, bearing and other moving components increases
significantly. So the generating set life will be shortened.
• Manufacturer recommends CC/CD oil classified by APl. Choose the applicable viscosity oil according to the
local ambient temperature.
NOTICE
STAGER YDE series generator set are equipped with low oil warning system. This system will stop the engine
automatically when the oil level falls below the lower level. This prevents accidents such as bearing seizures, etc.
Ver. 3/Rev. 2; Data: 8.08.2022 39
