Stacking
CAUTION
• Improper stacking method will cause the generator sets fall down and cause serious accidents.
• The generator must be placed on solid level surface.
• Only one unit may be stacked on another one and the outline dimension and weight of the unit on the top must
be smaller and lighter than the one on the bottom.
• Do not attempt to operate either generator while stacked. The vibration may cause one or both generators move
and fall.
Transportation
WARNING
• Lift the generator set with the lifting eye in the middle of the top cover or four lifting eyes at the bottom.
Otherwise the generator set may fall down due to insufficient strength. Or the generator set can be moved by
forklift.
• Don't stand under the generator set while it is lifted up.
• Don't lift or move the generator set in operation.
• Fix the unit properly when it’s transported by the truck.
2. MAIN TECHNICAL SPECIFICATION
Single phase generator sets:
Model
Item
YDE12000E YDE12000T YDE15000T
Rated frequency 50 Hz 50 Hz 50 Hz
Rated power 10 kVA 10 kVA 11 kVA
Maximum power 11 kVA 11 kVA 12 kVA
Rated voltage (CA) 230/115 V 230/115 V 230/115 V
Rated current (CA) 43.5/87 A 43.5/87 A 47.8/95.7 A
Rated speed 3000 r/min 3000 r/min 3000 r/min
Phase no. Single phase Single phase Single phase
Power factor (cos Φ) 1 1 1
Excitation mode AVR (self-excited, automatic voltage regulator)
Insulation class F F F
Pole number 2 2 2
Connecting Mode Transmission shaft rigid connection
Voltage output (DC) 12V - 36Ah 12V - 36Ah 12V - 36Ah
Starting system 12V electrical starter
Structure mode Open frame Silent Ultra silent
Weight 185 kg 260 kg 260 kg
Dimensions (Lxlxh) 1000 x 630 x 700 mm 1095 X 650 X 780 mm 1095 X 650 X 780 mm
Engine model YD2V88 YD2V88 YD2V92F
Engine type
Diesel engine, V-twin, 4-stroke, direct injection, air-
cooled
Diesel engine, V-two, vertical,
4-stroke, air-cooled
Rated power 13.8 kW / 3000 rpm 13.8 kW / 3000 rpm 14.8 kW / 3000 rpm
Bore x Stroke 88x75 mm 88x75 mm 92x75 mm
Displacement 912 ml 912 ml 997 ml
Compression ratio 20:1 20:1 20:1
Cooling system air-cooled air-cooled air-cooled
Lube oil capacity 2.3 L 2.3 L 2.4 L
Ver. 3/Rev. 2; Data: 8.08.2022 33
