7 Inspection and maintenance
01.2019 39
ba-o.1.8.0-en-3.1
7.8 Lubricate the chain
1. Have suitable lubricant to hand (see chapter “Lubrication points/lubricants”).
2. NOTICE Insufficient lubrication can lead to premature chain wear.
➢ Lubricate the entire length of the chain and all chain links.
7.9 Replacing load chain
WARNING
Danger from unsuitable chain
Use only original chain from the manufacturer as replacement.
Do not turn and refit a used chain suspension bolt!
Max. length of chain see sticker on chain box.
ST05
The welds of the upright chain links must point to the outside
over the chain sprocket.
Fig. 41
ST10 - ST60
Fig. 42
ST10 - ST32
short headroom with double chain guide
Fig. 43
WARNING
Danger of injury from moving chain
➢ Keep hands away from chain entry.
1. Attach a fitting aid, e.g. cable tie, to last link.
2. Let chain run into guide at slow speed as illustrated.
