Stahl ST10 - 8 Wearing Parts; Hoist

8 Wearing parts
46 01.2019
ba-o.1.8.0-en-3.1
8 Wearing parts
8.1 Hoist
Fig. 57
Fig. 58
Designation
ST05
ST10
ST20
ST30
ST32
ST50
ST 60
1*1
Chain
331 005 9
331 006 9
331 001 9
331 004 9
331 004 9
331 013 9
331 023 9
2
Chain drive
nBh
32 320 96 30 0
kBh
32 320 96 30 0
nBh
14 320 00 41 0
kBh
14 320 01 41 0
nBh
16 320 00 41 0
kBh
16 320 01 41 0
nBh
13 320 00 41 0
kBh
13 320 01 41 0
nBh
17 320 00 41 0
kBh
18 320 02 41 0
nBh
18 320 00 41 0
kBh
18 320 01 41 0
nBh
19 320 00 41 0
kBh
19 320 01 41 0
3
Chain stopper
32 320 01 27 0
14 320 01 27 0
16 320 01 27 0
20 320 00 27 0
20 320 00 27 0
18 320 02 27 0
18 320 02 27 0
4
Brake/slipping clutch
32 320 90 30 0
-
-
-
-
-
-
5
Brake / brake set
-
E21
14 320 09 64 0
E31
16 320 39 64 0
E31
16 320 39 64 0
E42
567 167 0 -100V
567 168 0 -190V
567 169 0 -240V
567 170 0 -290V
E42
567 167 0 -100V
567 168 0 -190V
567 169 0 -240V
567 170 0 -290V
E42
567 167 0 -100V
567 168 0 -190V
567 169 0 -240V
567 170 0 -290V
E22
14 320 10 64 0
E32
16 320 40 64 0
E32
16 320 40 64 0
E42-MF
18 320 36 64 0 -100V
18 320 37 64 0 -180V
18 320 38 64 0 -240V
18 320 39 64 0 -290V
E42-MF
18 320 36 64 0 -100V
18 320 37 64 0 -180V
18 320 38 64 0 -240V
18 320 39 64 0 -290V
E42-MF
18 320 36 64 0 -100V
18 320 37 64 0 -180V
18 320 38 64 0 -240V
18 320 39 64 0 -290V
6
Chain box
32 320 00 26 0
32 320 03 20 0
*2
12m
35 322 04 32 0
25m
33 320 26 26 0
8m
35 32204 32 0
16m
33 320 26 26 0
6m
35 320 04 32 0
10m
33 32026 26 0
6m
17 320 00 32 0
20 m
18 322 00 32 0
8m
18 320 00 26 0
12m
18 322 00 32 0
8m
18 320 00 26 0
12m
18 322 00 32 0
7
Suspension bolt
32 322 10 92 0
-
-
-
-
-
-
8
Suspension bolt
-
14 320 00 24 0
16 320 00 24 0
13 320 00 24 0
17 320 00 24 0
18 320 00 24 0
18 320 00 24 0
9
Bottom hook block 1/1
125 kg
32 320 00 59 0
250 kg
32 320 01 50 0
14 320 01 59 0
16 320 02 59 0
17 320 00 59 0
17 320 00 59 0
18 320 00 59 0
18 320 00 59 0
10
Bottom hook block 2/1
32 320 00 59 0
14 320 01 50 0
16 320 03 50 0
13 320 01 50 0
17 320 01 50 0
18 320 01 50 0
19 320 01 50 0
*1 Please state length
*2 For chain hoist with KE-T trolley
nBh = standard headroom
kBh = short headroom
