Stanley Alpha 120 User Manual

25
FIG. 42
Electrical Controls
SW/L COOKER
N/A
SW/L BOILER
N/A
PL - LIVE
PN - NEUTRAL
PL - LIVE
PN - NEUTRAL
L LIVE
N NEUTRAL
E EARTH
COOKER SWITCHED - LIVE
DO NOT USE
DO NOT USE
EXTERNAL PROGRAMMER - LIVE - MUST BE
CONNECTED DIRECTLY TO THIS SUPPLY
EXTERNAL PROGRAMMER - NEUTRAL
PUMP SUPPLY - LIVE (THE CIRCULATING PUMP MUST
BE CONNECTED DIRECTLY TO THIS SUPPLY)
PUMP SUPPLY - NEUTRAL (THE CIRCULATING PUMP
MUST BE CONNECTED DIRECTLY TO THIS SUPPLY)
3 AMP PERMANENT SUPPLY
NOTE:
The 3 channel programmer LIVE must be connected directly to the programmer LIVE supply from the cooker.
TERMINAL STRIP CONNECTIONS
BOILER SWITCHED - LIVE
