9
Burner Servicing
SEE FIG 12, 13A & 13B
It is recommended that each side of the burner is serviced
individually so as not to get the components from the two
burners mixed up.
The correct combination of burner blast tubes are shown.
To remove blast tube, slacken two grub screws, pull
forward.
120K
150K
INTRODUCTION
FIG. 12
FIG. 13B
FIG. 13A
DESN 512005
COOKER 10
VANES
COOKER 10
VANES
BOILER 10 VANES
5mm HOLES
10 LARGE SLOTS
BOILER 10 VANES
5mm HOLES
20 LARGE SLOTS
