Stanley BRANDON 80K Installation And Commissioning Instructions

Replace the Nylon handle with the chromed handle and reverse the above procedure - Step 5 - 1. See Fig. I
Using a small flat head screwdriver remove the circlip from the end of the door handle axle. See Fig.E & F.
Circlip
Removed
Fig.I
While holding the handle pull out the door handle axle. See Fig.G & H.
Circlip
Fig.G
Step 4
Step 5
Step 6
Grub Screw
Step 3
Fig.D
Fig.E
Fig.F
Fig.H
From the front face loosen the grub screw on the underside of the latch using the 2mm allen key. See Fig.D.
30
