Stanley BRANDON 80K Installation And Commissioning Instructions

100K
BOILER OUTPUTS: 29.3kW - 100,000 Btu’s/Hr.
RADIATOR SURFACE: 53 m
2
(571 ft.
2
) heating surface only.
48 m
2
(514 ft.
2
) heating surface and domestic hot water.
FLUE GAS FLOW: Boiler: 0.005m
3
/s Oven: 0.0026m
3
/s.
SPACE HEATING: 2.91 kW (10,000 Btu’s/hr) cooking mode / 0.7 kW (2,500 Btu’s/hr) boiler
mode.
FLUE GAS TEMPERATURE: Boiler: 180°C (356°F) Cooker: 250°C. (482°F)
BOILER CAPACITY: 17 litres (3.74 Gal.).
BOILER MATERIAL: Mild steel.
COOKER WEIGHT: 385Kg (850 lbs).
80K
BOILER OUTPUTS: 23.45kW - 80,000 Btu’s/Hr.
RADIATOR SURFACE: 42.5 m
2
(457 ft.
2
) heating surface only.
37.2 m
2
(400 ft.
2
) heating surface and domestic hot water.
FLUE GAS FLOW: Boiler: 0.0044m
3
/s Oven: 0.0026m
3
/s.
SPACE HEATING: 2.91 kW (10,000 Btu’s/hr) cooking mode / 0.7 kW (2,500 Btu’s/hr) boiler
mode.
FLUE GAS TEMPERATURE: Boiler: 200°C (392°F) Cooker: 230°C. (446°F)
BOILER CAPACITY: 17 litres (3.74 Gal).
BOILER MATERIAL: Mild Steel.
COOKER WEIGHT: 380Kg (838 lbs).
60K
BOILER OUTPUTS: 17.58kW - 60,000 Btu’s/Hr.
RADIATOR SURFACE: 32 m
2
(344.45 ft.
2
) heating surface only.
26.5 m
2
(285 ft.
2
) heating surface and domestic hot water.
FLUE GAS FLOW: Boiler: 0.0031m
3
/s Oven: 0.0026m
3
/s.
SPACE HEATING: 2.91 kW (10,000 Btu’s/hr) cooking mode / 0.7 kW (2,500 Btu’s/hr) boiler
mode.
FLUE GAS TEMPERATURE: Boiler: 170°C (356°F) Cooker: 250°C. (482°F)
BOILER CAPACITY: 17 litres (3.74 Gal.).
BOILER MATERIAL: Mild steel.
COOKER WEIGHT: 385Kg (850 lbs).
5
FUEL: 28 Sec Kerosene
MAINS CURRENT: 230v - 240v, 50 Hz A.C.
I.P. PROTECTION: IP 20
ELECTRICAL INPUT: 90 Watts
SUPPLY FUSE RATING:3A
MAX BOILER WORKING
PRESSURE: 1.9 bar 27.3 P.S.I.
TEST PRESSURE OF
BOILER: 3 bar 43.5 P.S.I
OPERATING TEMPERATURE
LIMIT IN BOILER: 96
o
C (205
o
F)
TECHNICAL DATA
