Stanley BRANDON 80K Installation And Commissioning Instructions

32
1. Cooker Burner - D00003BXX
2. Oil Burner Carrier Plate - Q00210AXX
3. Boiler Burner 100K - D00004BXX
Boiler Burner 80K - D00002AXX
Boiler Burner 60K - D00001AXX
4. 6” Bend - B00178AXX
5. Boiler Cleaning Door - B00187AXX
6. Hob Outer - B00192DXX
7. Flue Outlet Spigot - B00193AXX
8. Front Filler Casting - B00195AXX
9. Front - B00196CXX
10. Back Tile Trim - B00527AXX
11. Flue Cleaning Door - B00528AXX
12. Drip Tray - F00103AXX
13. Btm Cover Strip for Top Oven - F00119CXX
14. RH Side Cover Strip for Top Oven - F00120BXX
15. Control Cover Plate - F00126AXX
16. Oven Limit Stat Phial Clip - F00135AXX
17. Back Panel Blanking Plate - F00142BXX
18. Back Panel - F00154CXX
19. Side Panel RH - F00176AXX
20. Side Panel LH - F00177AXX
21. Burner Cover Plate (Oil) - F00767BXX
22. Base Edge Protectors - F00778AXX
23. Thermocouple Holder - F00785AXX
24. Insulation Panel For Oven Top - H00053AXX
25. Burner Ceramic Board - H00055BXX
26. Oven Wall Insul for Oven Firebox - H00185AXX
27. Boiler Assembly - L00076BXX
28. Hotplate Cover Assy RH - L00208AXX (B00221AXX)
29. Hotplate Cover Assy LH - L00209AXX (B00220AXX)
30. Warming Door Assy - L00361AXX (B00521AXX)
31. Control Door Assy - L00362AXX (B00522AXX)
32. Burner Door Assy - L00363AXX (B00523AXX)
33. Main Oven Door Assy - L00364AXX (B00520AXX)
34. Simmer Plate Cover Assy - L00367AXX (B00529AXX)
35. Base Assembly - L00368AXX (F00131AXX)
36. Control Panel Assembly - L00371AXX (B00525AXX)
37. Serial Number Plate - N00234BXX
38. Gasket For Simmering Plate - P00015AXX
39. Cleaning Plate Gasket - P00016AXX
40. Towel Rail Bracket Gasket - P00084AXX
41. Steam Escape - Q00107AXX
42. Shelf Diffuser - Q00126BXX
43. One Piece Oven Base - Q00168BXX
44. Warming Oven Cleaning Plate - Q00188AXX
45. Warming Oven Top - Q00189AXX
46. Simmering Plate - Q00198AXX
47. Hotplate - Q00200AXX
48. Inner Hob - Q00201CXX
49. Top Oven Bottom - Q00202AXX
50. Oven Top - Q00203BXX
51. Oven End Flue - Q00204AXX
52. Warming Oven Flue Divider - Q00205AXX
53. LH Inner Oven Side - Q00206BXX
54. LH Oven Side - Q00207AXX
55. Oven Back - Q00208BXX
56. RH Oven Side - Q00209AXX
57. Bar Short Horizontal Side Oven - Q00212AXX
58. Boiler To Oven Clamp - Q00697BXX
59. Door Hinge - U00029AXX
60. Towel Rail Bracket LH - U00106AXX
61. Towel Rail Bracket RH - U00107AXX
62. Oven Shelf - V00092BXX
63. Door Stop - V00116AXX
64. Thermostat Bulb Spacer - V00117AXX
65. Towel Rail - V00505AXX
66. Plinth - V00506AXX
BRANDON MK3 OIL 100K/80K/60K - PARTS & BOM CODES
67. Screw Cover - V00512AXX
68. Towel Rail Bung - V00522AXX
69. Stay Rod - V00563AXX
70. Steam Vent - W00904AXX
71. Door Catch - W00918AXX
72. Flue Increaser - Q00197BXX
73. Vertical Flue Adaptor - B00184AXX
74. Hinge (Simmer Plate) - U00125AXX
75. Hob Cleaning Door Gasket - P00023AXX
76. Simmer Plate Cover Plate - F00774AXX
77. Hinge (Hotplate Assembly) - U00067AXX
78. Hotplate Cover Stop - V00083AXX
80. Bend Door Gasket - P00017AXX
81. Hotplate Cover Dome - F00183CXX
82. Hotplate Cover Handle Bracket RH - U00027AXX
83. Hotplate Cover Spring Handle - U00026AXX
84. Hotplate Cover Handle Bracket LH - U00028AXX
85. Insulation Panel - H00074AXX
86. Insulation Panel - H00073AXX
87. Insulation Panel - H00072AXX
88. Boiler Cleaning Plate - F00133AXX
89. Brandon Top Insulation Panel - H00071AXX
90. Top Boiler Baffle - L00194AXX
91. Middle Boiler Baffle - L00199AXX
92. Bottom Baffle - L00200AXX
93. Insulation Panel - H00103AXX
94. Gasket Boiler to Oven - P00026AXX
95. Boiler Blanking Plug - V00016AXX
96. Thermocouple - G00270AXX
97. Grill For Roasting Tin - V00099AXX
98. Roasting Tin - V00091AXX
99. Thermistor - G00268AXX
100. Bus Wire - G00269AXX
101. Round Hotplate Cover Filler RH - Q00617AXX
102. Round Hotplate Cover FIller LH - Q00616AXX
103. Burner PCB Board - G00266AXX
104. Wiring ID Label - N00359AXX
105. Control Box Bracket -F00780AXX
106. Oven Limit Stat - G00018AXX
107. Limit Stat - G00267AXX
108. Boiler Stat Plate - F00370AXX
109. Grommet - V00155AXX
110. Divider Plate - F00128AXX
111. Control Box Cover - F00812BXX
112. Grommet - V00100AXX
113. Air Inlet Blanking Plate - F00775AXX
114. Spacer - F00141AXX
115. Oven Door Panel - F00765AXX
116. Warming Oven Panel - F00151AXX
117. Door Handle RH - U00105BXX
118. Door Handle LH - U00104BXX
119. Door Handle Axle - V00105AXX
120. Door Latch - V00504BXX
121. Door Handle Bracket LH - V00103AXX
122. Door Handle Bracket RH - V00104AXX
123. Door Handle Insulation - J00127AXX
124. Thermometer - G00261AXX
126. Burner Door Panel - F00150AXX
127. Fire Door Panel - F00764AXX
128. Door Latch Adjuster - F00808BXX
129. Spring - V00564AXX
130. Setting & Op Controller Label - N00331BXX
131. Control Panel Glass - T00038AXX
132. Timer Unit PCB Board - G00264AXX
133. Hotplate Cover Insulation - Round - J00219AXX
134. Hotplate Cover Insulation - Square - J00134AXX
135. Burner Cover Plate Insulation - J00030AXX
136. Control Cover Plate Padding - J00028AXX
137. Burner Carrier Plate Insulation - J00091AXX
