Mounting the Easikey 250 Controller
The controller should be mounted in a lockable cabinet or enclosure containing the power
supply and batteries, if used. It should be easily accessible for programming — the display
should be at about eye level.
Note: The Easikey 250 has the same dimensions as the Easikey 99.
198
90
39 120 39
40
50
Easikey 250 Mounting Plate Dimensions (mm)
14
