Star Micronics NX-1500 - Component Layout; Parts List

– 92 –
8-2. Component Layout
8-3. PartsList
Parallel Straight Board
R1 06041521 RD RESISTOR 1.5 K-OHM 1/4W 1
CN1 09100155 CONNECTOR 57L-40360-770B-D147 1
CN2 09100327 CONNECTOR AKD-30DLMDB2R 1
J1-2 93930001 JUMPER WIRE STP123 2
J3 NOT MOUNTED
J4 93930001 JUMPER WIRE STP123 1
F1 #1 93930001 JUMPER WIRE STP123 1 P=15mm
DRWG.NO. REV. PARTS NO. PARTS NAME Q'TY REMARKS RANK
[Old Board] [New Board]
