Star Trac 8-TRx - Page 46

Page 46
Error
Code
Name Description Diagnosis
Command
Used
21
ERR_FIT_DISP_READY_RESP_TIME-
OUT
Timeout waiting for query id from
FitCPU. This is reported when the
Display times out waiting for a query
id command from the FitCPU during
boot up.
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
comms cable between the Display and
the FitCPU .
3) If the problem still persists change
the comms cable .
4) If the problem still persists change
the FitCPU board.
DISP_ERROR
22 ERR_DISP_STARTUP_TIMEOUT
Timeout during startup hand shaking.
This is reported when the Display
times out waiting for a go to idle com-
mand from the FitCPU during boot up.
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
comms cable between the FitCPU and
the xCB .
Also check the comms cable between
the Display and FitCPU .
3) Also check the error code that is
being ashed on the FitCPU .
It may be dierent than the one being
displayed on the display .
Check this error code in the error codes
table .
4) If the problem still persists change
both of the comms cable.
DISP_ERROR
23 ERR_FIT_WDG_RESP_TIMEOUT
Fit CPU watchdog response timeout.
This is reported when there is no com-
munication between the Display and
the FitCPU for more than 2 seconds.
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
comms cable between the FitCPU and
the Display .
3) If the problem still persists change
the comms cable.
DISP_ERROR
24
ERR_FIT_INVALID_PROG_PARAME-
TERS
Fit reports invalid program parame-
ters. This indicates that the program
parameters were reported as invalid by
the FitCPU.
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
comms cable between the FitCPU and
the Display .
3) If the problem still persists change
the comms cable.
DISP_ERROR
25 ERR_FIT_INVALID_PROG_PROFILE
Fit reports invalid program prole. This
indicates that the program prole was
reported as invalid by the FitCPU.
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
comms cable between the FitCPU and
the Display .
3) If the problem still persists change
the comms cable.
DISP_ERROR
26 ERR_FIT_DISP_OUT_OF_SYNC
Fit CPU and Display are out of sync.
This is reported if the FitCPU and
Display workout modes are not syn-
chronized.
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
comms cable between the FitCPU and
the Display .
3) If the problem still persists change
the comms cable.
DISP_ERROR
