Star Trac 8-TRx - Page 48

Page 48
Error
Code
Name Description Diagnosis
Command
Used
37
ERR_CCB_CONFIG_MSG_RESP_TIM-
EOUT
Timeout waiting for CCB cong
message response. This is reported
when the Display does not receive a
cong message response from the CCB
during boot up.
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
comms cable between the Display and
the FitCPU .
3) If the problem still persists change
the comms cable.
DISP_ERROR
38
ERR_MCB_INCL_CAL_VAL_OUT_OF_
RANGE
Fit CPU reports MCB error status:- In-
cline calibration value out of range
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
Product Model in Maintenance Mode
and ensure it is correct .
3) Re-calibrate the Incline.
FIT_ERROR
39
ERR_MCB_SPD_CAL_VAL_OUT_OF_
RANGE
Fit CPU reports MCB error status:-
Speed calibration value out of range
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
Product Model in Maintenance Mode
and ensure it is correct .
3) Re-calibrate the Speed.
FIT_ERROR
40 ERR_MCB_SPEED_LOST
Fit CPU reports MCB error status:-
Speed lost (RPM Sensor)
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
Product Model in Maintenance Mode
and ensure it is correct .
3) Re-calibrate the Speed .
4) If the problem persists check the
speed sensor .
Rotate the ywheel on the motor and
ensure that the speed sensor LED on the
MCB blinks as the ywheel is moving.
FIT_ERROR
41
ERR_MCB_INCL_FDBACK_OUT_OF_
RANGE
Fit CPU reports MCB error status:- In-
cline feedback out of range
1) Re-boot the unit and see if the prob-
lem goes away .
2) If the problem persists, check the
Product Model in Maintenance Mode
and ensure it is correct .
3) Re-calibrate the Incline .
4) If the problem persists, check to see
that the Incline Counts value in the
Incline Calibration Screen is changing
during incline calibration .
The Incline Counts should go down as
the elevation goes up .
5) If the Incline Counts is not changing
during calibration, then the cable from
the elevation motor to the MCB should
be checked .
If the cable is OK then the elevation
motor should be replaced.
FIT_ERROR
