Star TSP700II SERIES User Manual

– 6 –
3-2-2. RS-232C Interface Cable
(1) Make sure the printer is turn off.
CAUTION
Before connecting/disconnecting the interface cable, make sure that power to the printer and
all the devices connected to the printer is turned off. Also make sure the power cable plug is
disconnected from the AC outlet.
(2) Connect the interface cable to the connector on the rear panel of the printer.
(3) Tighten the connector screws.
3-2-3. USB Interface Cable
Affix the ferrite core onto the USB cable as shown in
the illustration below and make sure to pass the cable
through the cable support as shown in the illustra-
tion.
RS-232C
interface
cable
4 cm (maximum)

Star TSP700II SERIES Specifications

General

Print Speed	250 mm/sec
Resolution	203 dpi
Print Method	Direct Thermal
Paper Width	80 mm
Connectivity	USB, Ethernet, Serial, Parallel
Cutter	Guillotine (Partial Cut)
