Steadicam
®
Padded Dock
The new dock
The padded dock is designed to protect the Volt electronics as well as make docking and balancing
easier. The low-prole design ensures nothing contacts the Volt gimbal motor assembly when docked,
and the “over-center” arm swings into place to secure the sled. Docking on the gimbal also reduces
shock loads on your gimbal bearings. You’ll enjoy a low, primary balance stud on the side, which is
barely higher than your gimbal handle, making it a simple task to lift for balancing regardless of the sled
build. And the dynamic balance stud is adjustable in length to clear your rig for endless spins.
MDR-3 mount
Dynamic balance stud
Tool holder
Arm holder
Padded dock insert
specic for your gimbal
Static balance stud
Over-center hook Hook lock lever
Dock tilt lock knob
Stand lock knob
Components
