Steinberg UR22 - Technical Specifications; Input and Output Specs

Appendix
UR22 Operation Manual 17
Specifications
Technical Specifications
MIC INPUT 1/2 (Balanced)
Maximum Input Level ±0 dBu
Input Impedance 4 kΩ
GAIN Range +10 dB to +54 dB
LINE INPUT 1/2 (Balanced)
Maximum Input Level +24 dBu
Input Impedance 20 kΩ
GAIN Range -14 dB to +30 dB
HI-Z INPUT 2 (Unbalanced)
Maximum Input Level +5.8 dBV
Input Impedance 1 MΩ
GAIN Range +0.8 dB to +44.8 dB
LINE OUTPUT 1/L 2/R (Impedance balanced)
Maximum Output Level +10dBu
Output Impedance 150 Ω
PHONES
Maximum Output Level 6 mW+6 mW, 40 Ω
USB
Specification USB2.0, 24 bit, 44.1 kHz/48 kHz/88.2 kHz/96 kHz/176.4 kHz/192 kHz
XLR INPUT
Polarity Pin 1: Ground
Pin 2: Hot (+)
Pin 3: Cold (-)
