Description of the device
UR22 Operation Manual 6
• Do not connect or disconnect a device while turning
on the [INPUT 2 HI-Z] switch. Doing so can damage
the connected device and/or the unit itself.
•To protect your speaker system, leave the
monitor speakers turned off when turning the
[INPUT 2 HI-Z] switch on/ off. It’s also a good idea
to turn all output level controls down to their
minimum. Neglect of these precautions may
result in large noise bursts that may damage
your equipment, your ears, or both.
8 [MIX] knob
Adjusts the signal level balance between the
signal from the analog input jacks and the signal
from an application software, such as DAW. This
control does not affect the signal sent to the
computer.
9 [PHONES] knob
Adjusts the output signal level of the [PHONES]
jack. This output signal level is not affected by the
[OUTPUT] knob.
) [PHONES
（）] jack
For connection to a set of headphones.
! [OUTPUT] knob
Adjusts the output signal level of the [LINE
OUTPUT] jacks.
