4.4 Multiwinch
The Multiwinch is mounted on the cage with the Orbit – Bracket for ring and is controlled by the PSU via
a control desk or a computer with the camera software installed. The winch is connected to the PSU
with its own cable.
The winch controls the camera vertically and horizontally in the cage and has a built-in function which
prevents the rope from being driven without stretch.
Table 4 Specifications Multiwinch
Specifications
Material
Stainless steel, POM and
aluminium
Weight
11 kg
Operating voltage
50 VDC nominal
Voltage tolerance
-25% / +50% (37,5 VDC / 75 VDC)
Temperature range
-20°C - +50°C
IP degree
IP67
Fixed cable
5 m
Figure 4 Multiwinch
