4 TECHNICAL DESCRIPTION
Steinsvik AS camera system is an advanced surveillance system to control the feeding of fish in
aquaculture and for general inspection of fish in cages.
The camera system consists of:
- Underwater camera
- Surface camera
- PSU
- Multiwinch
- Bracket for ring
- Antenna
- Aluminium pipe (mast)
- Strain relief (fibre installation only)
- Surveillance camera
- Camera cable
- Pulley for camera rope
- Pulleyblock 18 mm
- Counterweight
- Rope
Camera installation
Surface camera
Protection box PSU
Strain relief (only for
fiber installation)
PSU
Bracket for
ring
Multiwinch
Pulleyblock for camera rope
Rope
Underwater camera
Counterweight
Pulleyblock 18mm
Mast
Camera cable
