Specifications 21
Chapter 4 - Specifications
Model 10621 Crane
SPECIFICATION SHEET
Crane Rating: 60,000 ft-lbs (8.29 ton-meters)
Standar
d Boom Length: 11’0” (3.35 m) from CL of Crane
Boom Extension: 1st stage: Hydraulic 60"(152.4 cm)
2nd stage: Hydraulic 60"(152.4 cm)
Maximum Horizontal Reach: 21’0”(6.40 m) from CL of Crane
Maximum Vertical Lift: 23’(7.01 m)
(from crane base)
Boom Elevation: -5 to +80 degrees
Stowed Height 35.5” (90.2 cm)
(crane only)
Mounting Space Required 20 x 21 inches (50.8 x 53.3 cm)
Approximate Shipping Weight 2150 lbs (975 kg)
Controls Radio control standard
for all functions.
Winch Specification
Rope Diameter: 7/16" (1.11 cm)
Line pull speed: 60 ft/min (18.29 m/min)
Max. single part line: 5000 lbs (2268 kg)
Max. double part line: 10000 lbs (4535 kg)
Rotation: 400 degree power
(worm gear)
Lifting Capacities 5455 lbs @ 11’0"(2475 kg @ 3.35m)
3750 lbs @ 16’0"(1700 kg @ 4.88m)
2855 lbs @ 21’0"(1295 kg @ 7.01m)
Power Supply Required PTO & Pump
(8 gpm @ 3000 psi)
(30.3 lpm @ 207 bars)
*Subject to change without notification
