Installation 29
Chapter 6 - Installation
Installation Notice
According to Federal Law (49 cfr part 571),
each final-stage manufacturer shall
complete the vehicle in such a manner that
it conforms to the standards in effect on the
date of manufacture of the incomplete
vehicle, the date of final completion, or a
date between those two dates. This
requirement shall, however, be superseded
by any conflicting provisions of a standard
that applies by its terms to vehicles
manufactured in two or more stages.
Therefore, the installer of Stellar cranes and
bodies is considered one of the
manufacturers of the vehicle. As such a
manufacturer, the installer is responsible for
compliance with all applicable federal and
state regulations. They are required to
certify that the vehicle is in compliance with
the Federal Motor Vehicle Safety Standards
and other regulations issued under the
National Traffic and Motor Vehicle Safety
Act.
Please reference the Code of Federal
Regulations, title 49 - Transportation, Volume
5 (400-999), for further information, or visit
http://www.gpoaccess.gov/nara/index.html
for the full text of Code of Federal
Regulations.
Notice:
PTO and Pump installation instructions are
provided by the corresponding
manufacturers. For more information on
which PTO and Pump fit your application,
please contact your local Stellar Distributor
or Stellar Customer Service.
Applicable Chassis: 19000 GVWR and up.
Cab to Axle: 84” (213.36 cm)
Body Length Nominal: 133” (337.82 cm)
Body Height: 52” (132.08 cm)
Body Width: 94” (238.76 cm)
Compartment Depth: 22” (55.88 cm)
Floor Width: 50” (127 cm)
Net Weight: 3600 lbs (1632.93 kg)
Optimal Service Body
for the 10621 Crane:
T3-11 Service Body
Notice: Read this Page Before Installation of the Crane
The following pages will give a basic
overview of the installation process for the
Stellar 10621. Please read through them
entirely and obtain a clear understanding of
the process before proceeding.
General Installation
This chapter is designed to serve as a
general guide for the installation of a Stellar
10621 Telescopic Crane on a Stellar Service
Body. Each installation is considered unique
so certain portions of this chapter may or
may not apply to your direct application. If
a question should arise during the installation
process, please contact Stellar Customer
Service at (800) 321 3741.
This crane is designed for use with a Stellar
Service Body installed on a vehicle that
meets the minimum chassis requirements of
the crane. Check with Stellar Industries
before installing this crane on a body other
than a Stellar Service Body.
Important: When installing welder units to
the service bodies, it is highly
recommended that a surge protector is
installed on the chassis batteries to
protect the crane radio receiver, wiring
and other electronic devices from an
unexpected electrical spike or surge.
Failure to do so could result in extensive
damage to the service body and crane
electrical circuit.
