stellar labs 10621 - Extension Cylinder Assembly - PN 28859

Assembly Drawings 41
1
2
8
7
3
4
5
6
9
.YT
Q
NOI
T
PI
R
CSEDT
R
APMETI
113980P CYLINDER 13980 PAINTED 1
2 14442 TUBE ASM 0.38X23.25 EXT CYL 6620 1
3 14443 TUBE ASM 0.38X102.25 EXT CYL 6620 1
4 14115 MANIFOLD ASM 6620 EXT CBBD-LJN-XVN 1
514601 CAP SCR 0.38-16X2.25 SH ZC 1
611882 CAP SCR 0.38-16X1.75 SH ZC 2
718701 CLAMP PORT TUBE ZR518 1
824729 HOSE CLAMP #52 3.00 - 3.75 1
1SS 4
2
# P
M
ALC ESOH0664C9
P/N 28859
C
ylinder
Serial Tag
Location
Extension Cylinder Assembly - PN 28859
Note: Upper/Lower
Extension Cylinder uses
Stellar Seal Kit P/N 20450
