stellar labs 10621 - Chapter 7 - Assembly Drawings; Base Assembly - PN 18027

Assembly Drawings 35
.YTQNOITPIRCSEDTRAPMETI
1 11453 BEARING SWING DRIVE CAST BASE 6620 1
1
E
D
ILS 004 0283 POTS245112
3 C6069 MOTOR HYD ROSS MK080613AAAB 1
4D1307 CAP SCR 0.50-13X1.25 SH 2
5 44551PC GUARD TTB 6620 CRANE LZR 1
613959 CAP SCR 1.00-8 X .63 PLASTIC 2
2TALF 52.0 REHSAW04307
80479 CAP SCR 0.25-20X0.75 HHGR5 2
9 21151 GASKET MOTOR 008-10056-1 1
10 D1345 FTG CPRSN 0.12NPT/0.25 TUBE 2
11 D1810 TBE AIR SAEJ844 TYPE A .25 (28") 1
131.0 EPIP RELPUOC GTF6522C21
1THGIARTS TPN 8/1 KREZ2951c31
11
10
8
7
1
6
2
3
4
9
GASKET SHOWN AS REFERENCE
13
12
10
5
PN 18027
Base Assembly - PN 18027
Chapter 7 - Assembly Drawings
