19Specifications 19
Chapter 4 - Specifications
Model 6000 Crane
SPECIFICATION SHEET
Crane Rating: 60,000 ft-lbs (8.30 ton meters)
Standard Boom Length: 11’ (3.35 m) from CL of Crane
14’ (4.27 m) from CL of Truck
Boom Extension: Hydraulic 32" (81.3 cm)
Maximum Horizontal Reach: 14’ (4.27 m) from CL of Crane
17’ (5.18 m) from CL of Truck
Maximum Vertical Lift: 20’ (6.10 m) from Truck Frame
(From Truck Frame)
Cylinder Specifications
Inner Lift Cylinder: 6” (15.24 cm) bore with integral pilot
operated counterbalance valves.
Outer Lift Cylinder: 5” (12.70 cm) bore with integral pilot
operated counterbalance valves.
Extension Cylinder: 3” (7.62 cm) bore with integral pilot
operated counterbalance valves.
Rotation: 290 degree power
(Worm Gear Drive)
Lifting Capacities: 10,000 lbs @ 9’ (4535 kg @ 2.74 m)
(From CL of Truck) 4,250 lbs @ 17’ (1930 kg @ 5.18 m)
Power Supply Required: PTO & Pump
(6.0 gpm @ 2850 psi)
(22.7 lpm @ 197 bars)
Controls: Proportional Radio Controls standard for all
functions.
Stowed Height: 75” (190.5 cm) above Truck Frame
(Above Truck Frame)
Mounting Space Required: 32” (81.3 cm)
Approximate Shipping Weight: 3,150 lbs (1,430 kg)
