PN 22140
35
19
4
5
22
21
22
22
23
6
22
7
9
8
26
27
29
28
30
13
12
3
11
14
40
2
17
16
24
25
15
1
8
18
20
18
31
32
33
34
33
39
FOR REFERENCE
2) TRIM EDGE IS NOTED
BY IT'S PART NUMBER
36
C4759
C5470(2)
C5470(2)
C4739
37
25
24
38
38
NOTES:
1) GASKET SHOWN
10
.YTQNOITPIRCSEDTRAPMETI
1ENARC 0006 ESAB98741
10006 ELDDASCP29742
3 4032 BEARING SWING DRIVE 60001
4 4817OUTRIGGER LEG SS 60001
105.52X00.2 REDNILYC3770D5
6 4816OUTRIGGER LEG CS 60001
7 3783 CYLINDER 2.00X18.75 PAINTED BLK1
8C5902 WASHER 0.63 SAE FLAT YELLOW GR8 24
9 D1313 CAP SCR 0.63-11X4.00 HHGR8 ZY 20
10 D1312 CAP SCR 0.63-11X3.50 HHGR82
11 24868 NUT 0.63-11 HHGR8 NYLOCK ZY2
12 0343WASHER 0.31 USS FLAT ZINC4
13 0420 CAP SCR 0.31-18X0.75 HHGR54
14 11458 MOTOR HYD 10 CU IN/ PNT BLK1
1MSA PAC REGGIRTUO8429151
16X83.3X3 KCOD REPMUB549361
17 0504 CAP SCR 0.50-13X3.00 HHGR52
18 C6106NUT 0.50-13 HHGR5 NYLOC6
19 0352WASHER 0.50 USS FLAT ZINC8
20 0500 CAP SCR 0.50-13X1.75 HHGR54
1RS 52.3X00.1 NIPPZ219412
22 3875SNAP RING 1.00 INTERNAL4
157.3X00.1 NIPPZ7790D32
24 9320PIN CAP 0.44X1.75X0.19 SS4
2T&D52.6X00.1 NIPPZ8861152
26 4876PCPLATE SWITCH MTG 60001
27 0479 CAP SCR 0.25-20X0.75 HHGR52
28 10974 VB 2 SECT W/PB VDM6-4-4-YE-HP1
29 0489 CAP SCR 0.31-18X2.50 HHGR52
2COLYN HH 81-13.0 TUN243003
1THGIARTS TPN 8/1 KREZ2951c13
131.0 EPIP RLPC GTF6522C23
33 D1345 FTG CPRSN 0.12NPT/0.25 TUBE2
34 D1810 TBE AIR SAEJ844 TYPE A .25 (RM)1
35 21151 GASKET MOTOR 008-10056-11
36 30490CAP ASM OUTRIGGER SLANT 1
37 7341PLUG 0.50 NICKEL PLATED1
38 0351 CAP SCR 0.38-16X1.00 HHGR54
39 44605PCGUARD TTB 6000 CRANE LZR1
40 62484 CAP SCR 12MMX40MM SH2
