39Replacement Parts 39
Chapter 9 - Replacement Parts
Call 800-321-3741 to Order
HYDRAULIC SYSTEM COMPONENTS
PART# DESCRIPTION
6397 OIL PRESSURE GAUGE
24960 FLOW VALVE (PROPORTIONAL)
25369 SEAL KIT (FLOW VALVE)
25367 RELIEF VALVE
25368 SEAL KIT (RELIEF VALVE)
25371 SOLENOID VALVE (TANDEM)
25372 SOLENOID VALVE (OPEN) - ROTATION FUNCTION
25373 SEAL KIT (TANDEM AND OPEN VALVES)
44532 COIL (FLOW VALVE AND SOLENOID VALVES)
49315 PRESSURE SWITCH (OVERLOAD)
9803 COUNTER BALANCE VALVE (CYLINDERS)
11458 HYDRAULIC SWING MOTOR
21151 GASKET (HYDRAULIC SWING MOTOR)
C2027 O RING (#4 FACE SEAL) (HYDRAULIC FITTINGS)
C2028 O RING (#6 FACE SEAL) (HYDRAULIC FITTINGS)
C2029 O RING (#8 FACE SEAL) (HYDRAULIC FITTINGS)
32223 O RING (#10 FACE SEAL) (HYDRAULIC FITTINGS)
D1245 O RING (#4 SAE PORT SIDE) (HYDRAULIC FITTINGS)
D1246 O RING (#6 SAE PORT SIDE) (HYDRAULIC FITTINGS)
D1247 O RING (#8 SAE PORT SIDE) (HYDRAULIC FITTINGS)
D1248 O RING (#10 SAE PORT SIDE) (HYDRAULIC FITTINGS)
1099 SEAL KIT (OUTRIGGER CYLINDER)
11377 SEAL KIT (MAIN CYLINDER 4656)
C6305 SEAL KIT (SECONDARY CYLINDER 4657)
1100 SEAL KIT (EXTENSION CYLINDER)
ASSEMBLY COMPONENT PARTS
PART# DESCRIPTION
4381 BUSHING 2.00" X 2.00"
4380 BUSHING 2.00" X 1.00"
4379 BUSHING 2.00" X 2.50"
C1592 GREASE ZERK 1/8 NPT STRAIGHT
9435 WEAR PAD 1.34" X 3.00" ROUND
9364 WEAR PAD 0.34" X 3.00" ROUND
3863 HOOK 5-TON
5440 COLLAR (HOOK)
5192 HITCH PIN 1.25" X 5.13"
#0110 SNAP RING 1.00" ID
#0108 SNAP RING 2.00" ID
10710 SAFETY LATCH
29458 WORM GEAR (ROTATION GEAR BEARING)
27184 BEARING AND SEAL KIT (ROTATION GEAR BEARING)
3945 BUMPER DOCK
ELECTRICAL COMPONENTS
PART# DESCRIPTION
22600 TOGGLE SWITCH (HETRONIC RADIO REMOTE)
16975 E-STOP SWITCH (HETRONIC RADIO REMOTE)
35447 HANDLE / TRIGGER ASM (HETRONIC RADIO REMOTE)
35916 CABLE BACK UP (HETRONIC RADIO REMOTE)
35441 BATTERY TUBE (HETRONIC RADIO REMOTE)
D0045 ALARM (OVERLOAD)
34102 TRANSMITTER (HETRONIC RADIO SYSTEM) NOTE: ORDER DECAL PN 34111
WHEN ORDERING.
34103 RECEIVER (HETRONIC RADIO SYSTEM)
C4815 TOGGLE SWITCH (OPTIONAL FLOODLIGHTS AND SPEED CONTROL)
COMPRESSOR COMPONENTS (SHD66 OPTIONAL)
PART# DESCRIPTION
3853 PILOT VALVE 145/175 PSI
C4913 SOLENOID VALVE (SHD66 COMPRESSOR)
C4914 PRESSURE RELIEF VALVE (SHD66 COMPRESSOR)
C0864 AIR PRESSURE SWITCH -HOBBS (SHD66 COMPRESSOR)
7471 LOW PRESSURE INTAKE VALVE ASSEMBLY (SHD66 COMPRESSOR)
7472 HIGH PRESSURE INTAKE VALVE ASSEMBLY (SHD66 COMPRESSOR)
SERVICE KITS / FILTERS / LUBRICATION
PART# DESCRIPTION
4559 AIR FILTER (SHD66 COMPRESSOR)
C6227 HYDRAULIC RETURN FILTER (CRANE / COMPRESSOR)
8825 SERVICE KIT - 200 HOUR (SHD66 COMPRESSOR)
8823 SERVICE KIT - 1-YEAR (CRANE / COMPRESSOR)
4460 MOLUBE GREASE-EXTERNAL GEAR TEETH FOR SWING GEAR BEARINGS)
C0087 SYNTHETIC COMPRESSOR OIL ( 1 QT )
MISCELLANEOUS COMPONENTS
PART# DESCRIPTION
51592 FLOOD LIGHTS (CRANE AND BODY)
5033 STROBE LIGHT (CRANE AND BODY)
