WHEEL REMOVAL
650/800/850 GUEPARD
89
1. The wheel turning direction mark.
1. Wheel conical nut (4 pcs.).
2. Lower the vehicle on the ground.
3. Tighten the wheel nuts with a special wrench
The wheel nuts tightening torque is 55 Nm
Wheel removal
1. Ease the wheel nuts.
2. Lift the vehicle and set it on a suitable frame support.
1. Wheel nut (4 pcs.).
3. Unscrew the nuts from the wheel and remove the wheel.
NOTЕ:_______________________________________
The arrow mark on the tyre indicates the wheel
turning direction. The wheels are attached with
conical nuts.
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
Wheel installation
1. Install the wheel (according to the mark indicating
the turning direction) and the wheel nuts.
