Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
74
The above picture show: the year 2010, “Y“ is the abbreviation of year, when need to modify,
press enter button, the figure in the lowest order start to flash, use left or right button to select the
figure required for modification. The selected figure start to flash. Then use up or down button to
modify the figure ,press the enter button to confirm the modification.
5 System date
The above picture show: 8 month 12 day. “d” is the abbreviation of day. When need ot modify,
press the enter button. The figure in the lowest order start to flash, use the left or right button to
select the figure required for modification. The selected figure starts to flash. Then use up or down
button to modify the figure, press the enter button to confirm the modification.
6 System time
The above figure show: 15 hour 36 minutes, T is abbreviation of time. Please note, the “T”
displayed in the integrated unit is always shown as that in the above figure, due to the confinement
of 7-segment code. When need to modify, press enter key the figure in the lowest order start to
flash. Use left or right key to select the figure required for modification. The selected figure starts
to flash. Then use the up or down button to modify the figure. Press the enter button to confirm the
modification.
7 Hoist way parameter
