Instruction Manual
for
AS380 Series Elevator Integrated Drive Controller
78
The parameter set the floor display code of each floor, the detailed operation is as follow: use up
or down button to select the floor needed to browse, for example, first floor, the screen will
display FLr-01 as above picture, the figure will last for 1 second, then the screen will display the
display code 1 of the floor, as the above picture. You will see 1, then FLr-01 and 1 alternatively
display, each of which last 1 second. Press the enter button, the figure in the lowest order of LED
display start to flash. Use the up and down button to select the figure, use the left and right button
to select the figure needed to input. The selected figure start to flash, which mean the figure input
stat is on, use up or down button again to select the figure need to input. Press the enter button to
finish the parameter modification. The selected figure stops flashing.
Login authorization is required for the floor display parameter modification. Once modify
parameter and press the enter button in non login stat, login menu will pop up
13 input type
Input type parameter
X input point
Input type parameter
GX input point
Input type parameter
HX input point
