Full Digital Stepper Drive DM542S
- 11 -
7. Faults alarm and LED flicker frequency
Flicker
Frequen
cy
Description to the Faults
1
Error occurs when the motor coil current exceeds the drive’s
current limit.
2
Voltage reference error in the drive
3
Parameters upload error in the drive
4
Error occurs when the input voltage exceeds the drive’s voltage
limit.
