Steris Harmony LED385 - Adjust Braking Force; Figure 6-3. Adjust Braking Force

6-6
P093932-203 Equipment Manual Maintenance
6.3.2 Adjust Braking Force If the lighthead does not automatically keep the proper position, it is
necessary to adjust the braking force.
See Figure 6-3.
Use a 2.5 mm hexagonal Allen wrench to increase the braking
force, rotating arm brake screws clockwise.
Figure 6-3. Adjust Braking Force
Wrench
Arm Brake Screw
Wrench
Arm Brake Screw
