Illustrated Parts Breakdown Equipment Manual P093932-203
STERIS is committed to ensuring your continued satisfaction. This
manual illustrates and identifies assemblies and components of the
Harmony
®
LED385 Examination Lighting System. All personnel
involved in the use and maintenance of this equipment must
carefully review and comply with the S
AFETY PRECAUTIONS (SECTION
1) and instructions contained in Maintenance (Section 6) of this
manual. Do not begin service of this examination lighting system
until you have become familiar with this information.
9.1 General Assemblies and components of the Harmony LED385 Examination
Lighting System are illustrated and identified on the following pages.
The part number, the description and the quantity required for each
usage are given. Each indentation in the description represents the
assembly level. The UNITS PER ASSEMBLY column is specific for
the given assembly or subassembly level.
IMPORTANT:
A listing of the
SAFETY PRECAUTIONS
to be observed when operating and servicing this
equipment can be found in
SECTION 1
of
this manual
. Do not operate or service the equipment until
you have been trained on this information
.
WARNING – PERSONAL
INJURY AND/OR EQUIPMENT
DAMAGE HAZARD: Repairs
and adjustments to this
equipment must be made only
by STERIS or STERIS-trained
service personnel.
Maintenance performed by
unqualified personnel or
installation of unauthorized
parts could cause personal
injury, result in improper
equipment performance, void
the warranty or result in costly
damage. Contact STERIS
regarding service options.
CAUTION – POSSIBLE
EQUIPMENT DAMAGE: To
prevent voiding the warranty
or damaging the equipment,
use only STERIS replacement
parts.
ILLUSTRATED PARTS BREAKDOWN
9
