11.1.2 Attaching machine to harness
1
2
1
2
002BA604 KN
► Attach the carabiner (1) to the carrying ring (2)
on the shaft.
► Balance the machine – see "Balancing the
Machine".
11.1.3 Disconnecting machine from harness
2
1
1
2
002BA606 KN
► Press down the bar on the carabiner (1) and
pull the carrying ring (2) out of the carabiner.
11.2 FS 360
11.2.1 Putting on the harness
3
002BA411 KN
1
2
► Put on the full harness (1).
► Adjust the length of the strap so that the cara‐
biner (2) is about a hand’s width below your
right hip.
► Attach the spring hook to the machine's perfo‐
rated rail (3).
► Find the right attachment point for the cutting
attachment you are using – see "Balancing the
Machine".
11.2.2 Attaching machine to harness
2
1
002BA631 KN
1
2
► Attach the carabiner (1) to the perforated
rail (2) on the drive tube.
English 11 Fitting the Full Harness
26 0458-743-0121-E

Stihl FS 260 Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Blade
Handle type	U-type handle
Engine power	2.7 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Rotational speed	9000 RPM
Number of strokes	2
Sound power level	114 dB
Fuel tank capacity	0.75 L
Vibration emission	3.8 m/s²
Engine displacement	41.6 cm³
Sound pressure level	102 dB
Cutting diameter (max)	480 mm
Power source	Gasoline

Weight and Dimensions

Length	1680 mm
Weight	7500 g
