9
002BA414 KN
8
8 Circular Saw Blade
9 Limit stop (for circular saw blades only)
29 Specifications
29.1 Engine
Single-cylinder two-stroke engine
29.1.1 FS 260, FS 260 C
Displacement:
41.6cm
3
Cylinder bore: 42 mm
Piston stroke: 30 mm
Engine power to ISO 8893: 2.0 kW (2.7 hp) at
9000 1/min
Idle speed: 2800 rpm
Cut-off speed (nominal
value):
12500 rpm
Max. output shaft speed
(cutting attachment drive):
9000 rpm
29.1.2 FS 360 C
Displacement:
37.7cm
3
Cylinder bore: 40 mm
Piston stroke: 30 mm
Engine power to ISO 8893: 1.7 kW (2.3 hp) at
8500 1/min
Idle speed: 2800 rpm
Cut-off speed (nominal
value):
12500 rpm
Max. output shaft speed
(cutting attachment drive):
9000 rpm
29.2 Ignition system
Electronic magneto ignition
Spark plug (suppressed): NGK CMR6H
Electrode gap: 0.5 mm
29.3 Fuel system
All-position diaphragm carburetor with integral
fuel pump
Fuel tank capacity:
750 cm
3
(0.75 l)
29.4 Weight
Dry, without cutting attachment and deflector
FS 260: 7.7 kg
Dry, without cutting attachment and deflector
FS 260 C-E: 7.8 kg
FS 360 C-E: 8.5 kg
29.5 Overall length
without cutting attachment
FS 260: 1685 mm
FS 260 C-E: 1685 mm
FS 360 C-E: 1790 mm
29.6 Equipment features
C Note concerning comfort features
E ErgoStart
29.7 Noise and Vibration Data
Noise and vibration data measurements on FS
units include idling and rated maximum speed
with the same duration of exposure.
For further details on compliance with Vibration
Directive 2002/44/EC see www.stihl.com/vib.
29.7.1 Sound pressure level L
p
to ISO 22868
with mowing head
FS 260: 102 dB(A)
FS 260 C: 101 dB(A)
FS 360 C: 99 dB(A)
with metal mowing attachment
FS 260: 100 dB(A)
FS 260 C: 100 dB(A)
FS 360 C: 98 dB(A)
29.7.2 Sound power level L
w
to ISO 22868
with mowing head
FS 260: 114 dB(A)
FS 260 C: 113 dB(A)
FS 360 C: 112 dB(A)
with metal mowing attachment
FS 260: 111 dB(A)
FS 260 C: 112 dB(A)
FS 360 C: 110 dB(A)
29.7.3 Vibration measurement a
hv,eq
to
ISO 22867
with mowing head Handle, left Handle,
right
FS 260:
5.8 m/s
2
5.7 m/s
2
FS 260 C:
5.8 m/s
2
5.7 m/s
2
FS 360 C:
2.5 m/s
2
2.0 m/s
2
with metal mowing
attachment
Handle, left Handle,
right
FS 260:
4.2 m/s
2
4.6 m/s
2
FS 260 C:
4.2 m/s
2
4.6 m/s
2
FS 360 C:
2.2 m/s
2
1.8 m/s
2
The K‑factor in accordance with Directive
2006/42/EC is 2.0 dB(A) for the sound pressure
level and sound power level; the K‑factor in
29 Specifications English
0458-743-0121-E 43

Stihl FS 260 Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Blade
Handle type	U-type handle
Engine power	2.7 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Rotational speed	9000 RPM
Number of strokes	2
Sound power level	114 dB
Fuel tank capacity	0.75 L
Vibration emission	3.8 m/s²
Engine displacement	41.6 cm³
Sound pressure level	102 dB
Cutting diameter (max)	480 mm
Power source	Gasoline

Weight and Dimensions

Length	1680 mm
Weight	7500 g
