28 Main Parts
14
12
11
20
18
5
4
2
1
15
17
3
8
9
10
13
19
20
6BA030 KN
#
7
6
16
21
FS 360
FS 260
1 Fuel cap
2 Carburetor adjusting screw
3 Starter grip
4 Shutter (winter operation)
5 Spark plug boot
6 Muffler
7 Guard plate
8 Throttle trigger
9 Stop switch
10 Throttle trigger lockout
11 Handlebar
12 Clamping screw
13 Carrying strip
14 Protection against wear
15 Choke lever
16 Manual fuel pump
17 Filter cover
18 Fuel tank
19 Carrying ring
20 Throttle cable retainer
21 Handle support
# Serial number
1
002BA412 KN
2
3
1 Mowing head
2 Deflector for mowing heads only
3 Blade
002BA417 KN
5
4
4 Metal mowing attachment
5 Deflector (for metal mowing attachments
only)
002BA413 KN
6
7
6 Shredder blade
7 Shredder deflector (only for shredding with
shredder blades)
English 28 Main Parts
