Stihl FS 260 User Manual

681BA275 KN
1.
2.
► Disconnect wire rod from the transport guard.
681BA276 KN
► Swing wire rod outwards.
► Fit transport guard on saw blade from below,
making sure the limit stop is properly seated in
the recess.
681BA277 KN
2.
► Swing wire rod into position.
► Hook wire rod to the transport guard.
14.5 Universal Transport Guard
681BA293 KN
681BA294 KN
1.
2.
► Disconnect wire rod from the transport guard
and swing it outwards.
2.
681BA295 KN
► Fit the transport guard on the cutting attach‐
ment from below.
► Attach wire rod to the hook on the transport
guard.
15 Operating Instructions
15.1 During break-in period
A factory-new machine should not be run at high
revs (full throttle off load) for the first three tank
fillings. This avoids unnecessary high loads dur‐
ing the break-in period. As all moving parts have
to bed in during the break-in period, the frictional
resistances in the engine are greater during this
period. The engine develops its maximum power
after about 5 to 15 tank fillings.
English 15 Operating Instructions
32 0458-743-0121-E

Stihl FS 260 Specifications

General

Type	Brush cutter
Cordless	Yes
Head type	Blade
Handle type	U-type handle
Engine power	2.7 hp
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Rotational speed	9000 RPM
Number of strokes	2
Sound power level	114 dB
Fuel tank capacity	0.75 L
Vibration emission	3.8 m/s²
Engine displacement	41.6 cm³
Sound pressure level	102 dB
Cutting diameter (max)	480 mm
Power source	Gasoline

Weight and Dimensions

Length	1680 mm
Weight	7500 g
