RE 109, RE 119, RE 129 PLUS
English
18
Rolling up the high-pressure hose and
storing the spray attachment
RE 109, RE 119
RE 129 PLUS
Store the machine in a dry room where it
is protected from frost.
If protection from frost cannot be
guaranteed, draw glycol-based
antifreeze – like that used in motor
vehicles – into the pump:
N Insert water intake hose in container
with antifreeze
N Insert spray gun without spray lance
in the same container
N Switch on the machine with the
spray gun open
N Actuate the spray gun until a
uniform jet emerges
N Keep leftover antifreeze in a sealed
container
2013BA020 KN
2013BA025 KN
2013BA021 KN
2013BA026 KN
Storing the Machine

Stihl RE 109 Specifications

General

Operating Pressure	100 bar
Maximum Pressure	120 bar
Water Throughput	440 l/h
Maximum Water Supply Temperature	40 °C
Hose Length	7 m
Power Cable Length	5 m
Sound Power Level	85 dB(A)
