Stihl RE 170 PLUS User Manual

0458-663-0121-A
16
English 7 Assembling the pressure washer
7.2.2 Inserting handle
► Press trigger switch lockout (1) and insert handle (2).
► Release trigger switch lockout (1) and insert handle (2)
until it audibly engages.
7.3 Attaching and removing the spray gun
7.3.1 Attaching the spray gun
► Push connector (1) into spray gun (2).
The connector (1) audibly engages.
► If the connector cannot be pushed easily into the spray
gun (2): Grease the gasket on the connector (1) with
grease for fittings.
7.3.2 Removing the spray gun
► Press and hold the locking lever (1).
► Pull out connector (2).
7.4 Attaching and removing the spray lance
7.4.1 Attaching the spray lance
► Push spray lance (1) into spray gun (2).
► Twist the spray lance (1) until it engages.
► If the spray lance (1) cannot be pushed easily into the
spray gun (2): Grease the gasket on the spray lance (1)
with grease for fittings.
1
2
0000-GXX-9168-A0
0000-GXX-5095-A0
1
2
0000-GXX-5096-A0
1
2
0000-GXX-4350-A0
1
2

Stihl RE 170 PLUS Specifications

General

Form factor	Upright
Hose length	- m
Cable length	5 m
Power source	Electric
Product color	Black, Orange
Pump material	Aluminum
Detergent tank	-
Maximum flow rate	648 l/h
Minimum flow rate	570 l/h
Sound power level	85 dB
Vibration emission	2.4 m/s²
Working pressure (max)	180 bar
Working pressure (min)	150 bar
Maximum water temperature	60 °C
AC input voltage	230 V
Power consumption (typical)	- W

Weight and Dimensions

Weight	31000 g
